R432008663 Aventics Series 840 4/2-Directional Valve

Image may represent a range of products. Product may vary based on listed specifications.

Aventics Series 840 4/2-Directional Valve, Electrical Activation, Diaphragm Poppet Valve, Single Solenoid, 4/2, with Air Spring Return, Soft Seal, Manual Override with Detent, 1/4 in. NPTF Compressed Air Connection Output, 200 l/min Nominal Flow, 1.5 to 10 bar Working Pressure, Plug Connection, EN 175301-803, Form C, IP65, Internal Pilot, 24 VAC Operating Voltage, Protected against Polarity Reversal, 20 mm Coil Width, 22.5 mm Pilot Valve Width, 100% Duty Cycle, 12 ms Switch-on Time, 12 ms Switch-off Time, -15 to 50 Deg C Ambient Temperature Range.

  • Manufacturer: Aventics
  • Brand/Division: Numatics
  • Product Category: Valves
  • Product Family: Series 840
  • Product Type: Directional Valves
  • Electrical Connection Size: "EN 175301-803, Form C"
  • Electrical Connection Type: Plug
  • IP Rating: IP65
  • Manual Override: With Detent
  • Max. Ambient Temperature: 50 °C
  • Min. Ambient Temperature: -15 °C
  • Nominal Flow Qn: 200 l/min
  • Operational Voltage: 24 VAC
  • Pilot: Internal
  • Typ. Switch-Off Time: 12 ms
  • Typ. Switch-On Time: 12 ms
  • Working Pressure: 1.5 to 10 bar

R432008663
