R412009298 Aventics Series AS5-ACD Air Preparation Unit

Image may represent a range of products. Product may vary based on listed specifications.

Aventics Series AS5-ACD Air Preparation Unit, 2-Part, Filter Pressure Regulator, Lubricator, Polycarbonate Reservoir, with PA Protective Guard, with Pressure Gauge, G 3/4 Port, Single Pressure Supply, 12300 l/min Nominal Flow, 5 Micron Filter Porosity, Semi-Automatic Condensate Drain, Open without Pressure, 1.5 to 16 bar Working Pressure, 0.5 to 8 bar Regulation Range, -10 to 50 Deg C Ambient Temperature Range, Can be Assembled into Blocks, Vertical Mounting, Lock Type: for Padlocks, Diaphragm-Type Pressure Regulator, with Relieving Air Exhaust, Exchangeable Filter Element, 87 cm^3 Filter Reservoir Volume, 181 cm^3 Lubricator Reservoir Volume.

Manufacturer: Aventics
Brand/Division: Numatics
LINKS_Browse All Aventics Products: /manufacturers/aventics
Product Category: Parts & Accessories
Product Family: Series AS5
Product Type: Air Preparation Units
Max. Ambient Temperature: 50 °C
Micron Rating: 5 µm
Min. Ambient Temperature: -10 °C
Nominal Flow Qn: 12300 l/min
Working Pressure: 1.5 to 16 bar
