R412007263 Aventics Series AS3-SOV 3/2-Directional Valve

Image may represent a range of products. Product may vary based on listed specifications.

Aventics Series AS3-SOV 3/2-Directional Valve, Pneumatical Activation, Poppet Valve, 4500 l/min Nominal Flow, Pipe Connection, G 1/2 Compressed Air Connection & Exhaust, G 1/8 Pilot Exhaust, Soft Seal, 0 to 16 bar Working Pressure, 2.5 to 16 bar Control Pressure, Can be Assembled into Blocks, -10 to 50 Deg C Ambient Temperature, 4500 l/min Nominal Flow Qn 1 to 2, 3200 l/min Qn 2 to 3, Polyamide Housing Material, Acrylonitrile Butadiene Styrene Front Plate, Acrylonitrile Butadiene Rubber Seal Material, Die-cast Zinc Threaded Bushing.

Manufacturer: Aventics
Brand/Division: Numatics
LINKS_Browse All Aventics Products: /manufacturers/aventics
Product Category: Valves
Product Family: Series AS3
Product Type: Directional Valves
Control Pressure: 2.5 to 16 bar
Housing Material: Polyamide
Max. Ambient Temperature: 50 °C
Min. Ambient Temperature: -10 °C
Seal Material: Acrylonitrile Butadiene Rubber
Working Pressure: 0 to 16 bar
