Image may represent a range of products. Product may vary based on listed specifications.
Aventics
Aventics Series AV05 5/2-Directional Valve, Electrical Activation, Spool Valve, Positive Overlapping, 5/2, with Spring/Air Return Spring, Soft Seal, Manual Override with Detent, 700 l/min Nominal Flow, -0.9 to 10 bar Working Pressure, IP65, External Pilot, -15 to 60 Deg C Ambient Temperature Range, 24 VDC Operational Voltage, -10% / +10% Voltage Tolerance, 0.55W Power Consumption, Yellow LED Status Display, 100% Duty Cycle, 17 ms Switch-on Time, 26 ms Switch-off Time, Polyamide Fiber-Glass Reinforced Housing Material.
- Manufacturer: Aventics
- Brand/Division: Numatics
- LINKS_Browse All Aventics Products: /manufacturers/aventics
- Product Category: Valves
- Product Family: Series AV05
- Product Type: Directional Valves
- Housing Material: Polyamide Fiber-Glass Reinforced
- IP Rating: IP65
- Manual Override: With Detent
- Max. Ambient Temperature: 60 °C
- Min. Ambient Temperature: -15 °C
- Nominal Flow Qn: 700 l/min
- Operational Voltage: 24 VDC
- Pilot: External
- Typ. Switch-Off Time: 26 ms
- Typ. Switch-On Time: 17 ms
- Working Pressure: -0.9 to 10 bar
Contact Our Gauge ExpertsFrequently bought together:
Related Products
AV05-5/3CC-VT00-024VDC-LOC Aventics Series AV05 5/3-Directional Valve
