5763990220 Aventics Series CD01-PA 2x3/2-Directional Valve

Image may represent a range of products. Product may vary based on listed specifications.

Aventics Series CD01-PA 2x3/2-Directional Valve, Electrical Activation, Spool Valve, Positive Overlapping, Base Plate DIN ISO 15401-1 Compressed Air Connection Input/Exhaust/Pilot Input/Pilot Exhaust, Base Plate DIN ISO 15407-1 Compressed Air Connection Output, Plate Conection, Soft Seal, with Detent, Free of Substances that Impair Surface Wetting in the Coating Process, 1010 l/min Nominal Flow, 2.5 to 10 bar Control Pressure, Internal Pilot, 24 VDC Operational Voltage, -10% / +10% Voltage Tolerance, 26 mm Pilot Valve Width, 1.6W Power Consumption, 26 mm Frame Size.

Manufacturer: Aventics
LINKS_Browse All Aventics Products: /manufacturers/aventics
Product Category: Valves
Product Family: Series CD01-PA
Product Type: Directional Valves
