5724555270 Aventics Series CD12 3/2-Directional Valve

Image may represent a range of products. Product may vary based on listed specifications.

Aventics Series CD12 3/2-Directional Valve, Electrical Activation, Spool Valve, Positive Overlapping, 3/2, with Spring Return, Soft Seal, with Detent, Internal Thread, G 1/2 Air Connection Output, 4000 l/min Nominal Flow, 2 to 10 bar Working Pressure, Plug Connection, EN 175301-803, Form A, IP65, Protected Against Polarity Reversal, Internal Pilot, 30 mm Coil Width, 30 mm Pilot Valve Width, Aluminum, Industrial, Polyamide, Fiber-Glass Reinforced, Compatibility Index 52, 34 ms Switch-on Time, 90 ms Switch-off Time.

Manufacturer: Aventics
LINKS_Browse All Aventics Products: /manufacturers/aventics
Product Category: Valves
Product Family: Series CD12
Product Type: Directional Valves
