R412017962 Aventics Series CL03-EV 5/2-Directional Valve

Image may represent a range of products. Product may vary based on listed specifications.

Aventics Series CL03-EV 5/2-Directional Valve, Electrical Activation, Single Solenoid, 2/2, with Spring/Air Spring Return, Yellow LED Status Display, Soft Seal, Manual Override with Detent, 8 mm Diameter Compressed Air Connection Output, 700 l/min Nominal Flow, -0.9 to 10 bar Working Pressure, IP65, IP67, IP69K, External Pilot, 24 VDC Operating Voltage, -15% / +20% Voltage Tolerance, 0.35W Power Consumption, Protected against Polarity Reversal, 16 mm Pilot Valve Width, 100% Duty Cycle, 16 ms Switch-on Time, 23 ms Switch-off Time, UR Certificate, 0 to 50 Deg C Ambient Temperature Range, Polyamide Fiber-glass Reinforced Housing Material.

  • Manufacturer: Aventics
  • Brand/Division: Numatics
  • Product Category: Valves
  • Product Family: Series CL03
  • Product Type: Directional Valves
  • Housing Material: Polyamide Fiber-Glass Reinforced
  • IP Rating: IP65/IP67/IP69K
  • Manual Override: With Detent
  • Max. Ambient Temperature: 50 °C
  • Min. Ambient Temperature: 0 °C
  • Nominal Flow Qn: 700 l/min
  • Operational Voltage: 24 VDC
  • Pilot: External
  • Typ. Switch-Off Time: 23 ms
  • Typ. Switch-On Time: 16 ms
  • Working Pressure: -0.9 to 10 bar

R412017962
