R412006229 Aventics Series AS2-LBS Standard Oil-Mist Lubricator

Image may represent a range of products. Product may vary based on listed specifications.

Aventics Series AS2-LBS Standard Oil-Mist Lubricator, Metal Reservoir, with Inspection Glass, G 1/4 Compressed Air Connection, 2800 l/min Nominal Flow, Semi-Automatic Oil Filling During Operation, Manual Oil Filling, 0.5 to 16 bar Working Pressure, -10 to 50 Deg C Ambient Temperature, 40 cm^3 Lubricator Reservoir Volume, 1-2 Drops Oil Dosing at 100 l/min, Vertical Mounting, Can be Assembled into Blocks, Polyamide Housing Material, Acrylonitrile Butadiene Styrene Front Plate, Acrylonitrile Butadiene Rubber Seal Material, Die-cast Zinc Threaded Bushing, Die-cast Zinc Reservoir.

Manufacturer: Aventics
Brand/Division: Numatics
LINKS_Browse All Aventics Products: /manufacturers/aventics
Product Category: Parts & Accessories
Product Family: Series AS2
Product Type: Lubricators
Housing Material: Polyamide
Max. Ambient Temperature: 50 °C
Min. Ambient Temperature: -10 °C
Nominal Flow Qn: 2800 l/min
Seal Material: Acrylonitrile Butadiene Rubber
Working Pressure: 0.5 to 16 bar
