4LO-C4L-5-BN-SS Parker IVD C Series Check Valve

Image may represent a range of products. Product may vary based on listed specifications.

Parker IVD C Series Check Valve, Poppet Valve, 1/4 in. Male SAE O-Ring Face Seal w/ Backup O-Ring Inlet & Outlet (Port 1 & 2), 5 psi Cracking Pressure, Nitrile Seat, 316 Stainless Steel Body, 6000 psig CWP, 0.75 Cv Max, -30 to 275 F Deg Temperature Rating.

Manufacturer: Parker Hannifin
DOCS_CATALOG: Parker Check Valves (C Series): https://cdn11.bigcommerce.com/s-ca10qrhzok/content/documents/parker-c-check-valves.pdf
Body Material: 316 Stainless Steel
End 1 Size: 1/4 in.
End 1 Type: Male O-Ring Face Seal with O-Ring
End 2 Size: 1/4 in.
End 2 Type: Male O-Ring Face Seal with O-Ring
Max. Temperature: 275°F
Pressure Rating: 6000 PSIG
Product Family: C Series
Seat Material: Buna-N
Brand/Division: Instrumentation Products
LINKS_Browse All C Series Products: /manufacturers/parker/c-series
LINKS_Browse All Parker Hannifin Products: /manufacturers/parker
Product Category: Valves
Product Type: Check Valves
