4916AHNPF Fairchild Model 4900A Pneumatic Volume Booster 1:1 ratio

Image may represent a range of products. Product may vary based on listed specifications.

Rotork Fairchild Products Model 4900A Pneumatic Volume Booster, 1:1 ratio, 250 psi [17 BAR] supply, 500 SCFM [850m3/Hr]@100 psi supply/20 psi set, 150 psi [10 BAR] max output, 3/4 BSPP line, 1/4 BSPP gau/sig, 3/4 BSPP exh, 1/4 FPT feedback port, Zn Plated Steel trim.

Manufacturer: Fairchild Products
Accuracy: 0.50 psi
Ambient Temperature: -40° to 200 °F (-40° to 93.3 °C)
Base Model: 4916A
Body Material: Aluminum
Elastomer: Nitrile on Polyester
Exhaust Capacity: 100 SCFM [170m³/hr] where downstream pressure is 5 psi above 20 psi setpoint
Exhaust Type: Straight (standard)
ExhaustCv: 9
Flow Capacity: 500 SCFM
FlowCv: 9
Mounting: Wall (21363-1 bracket required)
Operator: Pneumatic Pilot Signal
Options: [N] Nitrile [P] feedback port [F] Zinc plated steel trim
Pipe Size: 3/4 BSPP
Pressure Range: 0 to 150 psi
Product Family: Model 4900A
Product Type: Pneumatic Volume Boosters
Ratio: 1:01
RatioAccuracy: 0.5% of 100 psi output span
Sensitivity: 0.15 psi
Supply Pressure: 250 psi
