20W1005H02LVAC-AHK Ashcroft Commercial Pressure Gauge

Image may represent a range of products. Product may vary based on listed specifications.

Ashcroft 1005 Commercial Pressure Gauge, 1/4" MPT, -100 to 0 kPa/30 to 0" Hg, +/-3/2/3% Accuracy, 2" Aluminum Dial, Black Pointer, Bronze Bourdon Tube/Brass Socket, Black Painted Steel Case, Heat Resistant Push-In Polycarbonate Window, Power Flex with Polyester Segment Movement, Dry, Lower, Dual Scale, Commercial Pressure Gauge.

Manufacturer: Ashcroft
Accuracy: ± 3%
Connection Location: Lower Mount
Dial Material: Aluminum
Dial Size: 2 in.
Display Type: Dial
Enclosure Material: Painted Steel
Full-Scale Accuracy: ± 3%
Max. Pressure: 0 KPa/0 in. Hg
Mid-Scale Accuracy: ± 2%
Min. Pressure: -100 KPa/30 Inch Hg
Pointer Color: Black
Pointer Material: Aluminum
Product Family: 1005
Sensor Element: Bronze Bourdon Tube/Brass Socket
Temperature Rating: -40° to 150 °F (Ambient/Process/Storage)
LINKS_Browse All 1005, 1005P & 1005S Products: /manufacturers/ashcroft/1005-1005p-1005s
LINKS_Browse All Ashcroft Products: /manufacturers/ashcroft
DOCS_Ashcroft 1005, 1005P, 1005S Series Pressure Gauges Datasheet: https://cdn11.bigcommerce.com/s-ca10qrhzok/content/documents/ashcroft-1005-1005p-1005s-series-pressure-gauges-pg-45_46_86-catalog.pdf
Connection Size: 1/4 in.
Enclsoure Color: Black
Product Category: Pressure Gauges
Product Type: Commercial & Utility Gauges
Filled: Dry
Connection Type: MNPT
Case: Black Painted Steel
Pressure Range: -100 to 0 kPa
Pressure Range: 30 to 0 in Hg
