Aventics Series TC08 5/2-Directional Valve, Pneumatical Activation, Spool Valve, Positive Overlapping, 5/2, Double Air Pilot, Soft Seal, Pipe Connection, G 1/8 Compressed Air Connection Input/Output/Exhaust, M5 Pilot Input, 800 l/min Nominal Flow, -0.9 to 10 bar Working Pressure, 2 to 10 bar Control Pressure, External Pilot, -10 to 50 Deg C Ambient/Medium Temperature Range, 5 um Max Particle Size.
- Manufacturer: Aventics
- Brand/Division: Numatics
- LINKS_Browse All Aventics Products: /manufacturers/aventics
- Product Category: Valves
- Product Family: Series TC08
- Product Type: Directional Valves
- Control Pressure: 2 to 10 bar
- Max. Ambient Temperature: 50 °C
- Max. Medium Temperature: 50 °C
- Min. Ambient Temperature: -10 °C
- Min. Medium Temperature: -10 °C
- Nominal Flow Qn: 800 l/min
- Pilot: External
- Working Pressure: -0.9 to 10 bar
